Page 114 FT-950 OPERATING MANUAL
MODE-SSB GROUP
064 J3E TX BPF
Function: Selects the audio passband of the DSP modula-
tor on the SSB mode.
Available Values: 1-30/1-29/2-28/3-27/4-26
Default Setting: 3-27: 300 ~ 2700 (Hz)
1-30: 100 ~ 3000 (Hz)
1-29: 100 ~ 2900 (Hz)
2-28: 200 ~ 2800 (Hz)
3-27: 300 ~ 2700 (Hz)
4-26: 400 ~ 2600 (Hz)
NOTE:
The apparent power output, when using the widest band-
widths, may seem lower. This is normal, and it occurs be-
cause the available transmitter power is distributed over a
wider bandwidth. The greatest compression of power out-
put, conversely, occurs when using the “4-26” setting (400
~ 2600 Hz), and this setting is highly recommended for
contest or DX pile-up work.
065 J3E LSB CAR
Function: Adjusts the receiver carrier point for the LSB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
066 J3E USB CAR
Function: Adjusts the receiver carrier point for the USB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
RX GENERAL GROUP
067 RGEN NB 1 LVL
Function: Adjusts the noise blanking level of the IF Noise
Blanker for short duration pulse noise.
Available Values: 0 ~ 255
Default Setting: 128
068 RGEN NB 2 LVL
Function: Adjusts the noise blanking level of the IF Noise
Blanker for longer duration pulse noise.
Available Values: 0 ~ 255
Default Setting: 128
069 RGEN CNTR LV
Function: Adjusts the parametric equalizer gain of the
Contour filter.
Available Values: –40 ~ +20 dB
Default Setting: –15 dB
070 RGEN CNTR WI
Function: Adjusts the Q-factor of the Contour filter.
Available Values: 1 ~ 11
Default Setting: 10
071 RGEN DNF
Function: Enables/disables the Digital Notch Filter.
Available Values: OFF/On
Default Setting: OFF
072 RGEN DNR
Function: Set the Digital Noise Reduction response.
Available Values: OFF/1 ~ 15
Default Setting: OFF
MENU MODE
IF
BANDWIDTH
“+” Gain
“Q”
--
” Gain
CONTOUR “GAINAND “Q
