Yaesu FT2DR Instruction Manual

11
APRS
®
initial settings
Setting the symbol of your own station
This sets the transmit symbol of your own station. The symbol can be selected from
among 48 types.
The default setting when shipped from the factory is “
”, “ ”, “ ”, “ ”.
1 Press the key for one second or longer
The Set Mode Menu will appear.
2 Touch [APRS]
3 Turn the DIAL to select [25 MY SYMBOL] and touch it
on the display

Yaesu FT2DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
GPS	Yes
Waterproof Rating	IPX5
Bluetooth	Yes
Power Output	5 W
Modes	FM, C4FM
Weight	282 g
Operating Voltage	7.4V DC
Battery	7.4 V, 2200 mAh Li-Ion
