RF Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR.

C 1200 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b3

C 1201 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b3

C 1202 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b3

C 1203 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b3

C 1205 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 GERMANY 1- A C1

C 1205 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 USA 1- A C1

C 1205 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 EXPORT 1- A C1

C 1205 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 EXPORT 2- A C1

C 1206 CHIP CAP. 18pF 50V CH UMK105CH180JW-F K22178264 1- A C1

C 1207 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 USA 1- A C1

C 1207 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 EXPORT 1- A C1

C 1207 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 EXPORT 2- A C1

C 1207 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 GERMANY 1- A C1

C 1208 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 EXPORT 1- A C1

C 1208 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 GERMANY 1- A C1

C 1209 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 1210 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C2

C 1212 CHIP CAP. 56pF 50V CH UMK105CH560JW-F K22178276 1- A C1

C 1213 CHIP TA.CAP. 4.7uF 6.3V TESVSP0J475M-8R K78080053 1- A C1

C 1214 CHIP CAP. 120pF 50V CH UMK105CH121JW-F K22178284 1- A C1

C 1215 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1

C 1216 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1

C 1218 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B1

C 1219 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C2

C 1220 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B2

C 1221 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a1

C 1222 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A D1

C 1223 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C3

C 1224 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- B a2

C 1225 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B a2

C 1226 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a1

C 1227 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B3

C 1228 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A3

C 1229 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1230 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B3

C 1231 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a1

C 1232 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C2

C 1233 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A B1

C 1234 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- A B1

C 1235 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A B1

C 1236 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1237 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1238 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A B1

C 1239 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A B1

C 1240 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 1241 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 1242 CHIP CAP. 68pF 50V CH GRM39CH680J50PT K22174231 1- B b1

C 1244 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- B c1

C 1245 CHIP CAP. 39pF 50V CH UMK105CH390JW-F K22178272 1- B c1

C 1246 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 1247 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1248 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1249 CHIP CAP. 150pF 50V CH GRM39CH151J50PT K22174239 1- B b1

C 1250 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- B b1

C 1251 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 1253 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A D2

C 1254 CHIP TA.CAP. 22uF 4V TESVSP0G226M-8R K78060047 1- A A3

C 1255 CHIP TA.CAP. 2.2uF 4V TESVSP0G225M-8R K78060025 1- B a1

C 1256 CHIP TA.CAP. 10uF 6.3V TESVSP0J106M-8R K78080055 1- A A3

C 1257 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A3

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
