RF Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR.

C 1258 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1259 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A1

C 1260 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 1262 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A A1

C 1264 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B c1

C 1266 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- A A1

C 1267 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 1- B c1

C 1269 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- A A1

C 1270 CHIP CAP. 39pF 50V CH UMK105CH390JW-F K22178272 1- A A1

C 1271 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B c1

C 1272 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1273 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B c1

C 1274 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- B c1

C 1275 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B c1

C 1276 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1277 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B c1

C 1278 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 1- B c1

C 1279 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d1

C 1280 CHIP CAP. 39pF 50V CH UMK105CH390JW-F K22178272 1- B d2

C 1281 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- B c1

C 1282 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B d2

C 1283 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- B d1

C 1284 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B d1

C 1285 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2

C 1286 CHIP TA.CAP. 10uF 6.3V TESVSP0J106M-8R K78080055 1- B a1

C 1287 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a1

C 1288 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 1- A A1

C 1289 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- A A1

C 1290 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- B d1

C 1291 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- A A1

C 1292 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 1- B d1

C 1293 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- A A1

C 1295 CHIP CAP. 47pF 50V CH UMK105CH470JW-F K22178274 1- A A1

C 1296 CHIP CAP. 18pF 50V CH UMK105CH180JW-F K22178264 1- A A1

C 1297 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- A A1

C 1298 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- B c1

C 1299 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- B c1

C 1301 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B c1

C 1302 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2

C 1303 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2

C 1304 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2

C 1305 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c1

C 1306 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B c1

C 1307 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1

C 1308 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A C1

C 1309 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A D1

C 1310 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 USA 1- A C1

C 1310 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 EXPORT 1- A C1

C 1310 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 EXPORT 2- A C1

C 1310 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 GERMANY 1- A C1

C 1311 AL.ELECTRO.CAP. 100uF 16V ECEV1CA101WP K48120012 1- A B3

C 1312 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- A B2

C 1313 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 1314 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A2

C 1315 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- A B1

C 1316 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- A B2

C 1317 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b3

C 1319 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B a3

C 1320 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B d1

C 1322 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1-

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
