Yaesu VX-7R - TECHNICAL User Manual

26
RF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
C 1323 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-
D 1001 DIODE 1SS362 TE85R G2070268 1- A B1
D 1002 DIODE 1SS362 TE85R G2070268 1- B c2
D 1003 DIODE 1SS362 TE85R G2070268 1- B c2
D 1004 DIODE 1SV271 TPH3 G2070476 1- A A1
D 1005 DIODE HVC358B(TAPE) G2070590 1- A B1
D 1006 DIODE DAN222 TL G2070174 1- A B1
D 1007 DIODE DAN222 TL G2070174 1- A B1
D 1008 DIODE DAN222 TL G2070174 1- B c2
D 1009 DIODE DAN222 TL G2070174 1- B b2
D 1010 DIODE DAN222 TL G2070174 1- B c2
D 1011 DIODE DAN222 TL G2070174 1- B c2
D 1012 DIODE DAN222 TL G2070174 1- B d2
D 1013 DIODE HVR100-8TRU G2070540 1- B d2
D 1014 DIODE M1FM3-4063 G2070804 1- A C3
D 1015 DIODE HVC355B(TAPE) G2070588 1- A A2
D 1017 DIODE HVC355B(TAPE) G2070588 1- A A2
D 1018 DIODE HVC358B(TAPE) G2070590 1- A B2
D 1019 DIODE 1SV325(TPH3) G2070848 1- B b2
D 1020 DIODE HVC369B TRF G2070872 1- B b2
D 1021 DIODE 1SV325(TPH3) G2070848 1- B b2
D 1022 DIODE HVC369B TRF G2070872 1- B b2
D 1023 DIODE 1SV325(TPH3) G2070848 1- B b2
D 1024 DIODE 1SV325(TPH3) G2070848 1- B b2
D 1025 DIODE 1SV325(TPH3) G2070848 1- B c3
D 1026 DIODE 1SV325(TPH3) G2070848 1- B c3
D 1027 DIODE DAN222 TL G2070174 1- B d3
D 1028 DIODE DAN222 TL G2070174 1- B d3
D 1029 DIODE 1SS400 TE61 G2070634 1- A A2
D 1030 DIODE HVC358B(TAPE) G2070590 1- A B2
D 1031 DIODE HVC358B(TAPE) G2070590 1- A B2
D 1032 DIODE 1SS400 TE61 G2070634 1- A B2
D 1033 DIODE 1SV325(TPH3) G2070848 1- B b2
D 1034 DIODE 1SS400 TE61 G2070634 1- A B2
D 1035 DIODE 1SS400 TE61 G2070634 1- B b2
D 1036 DIODE 1SV325(TPH3) G2070848 1- B b2
D 1037 DIODE 1SS400 TE61 G2070634 1- B c3
D 1038 DIODE 1SS400 TE61 G2070634 1- B c3
D 1039 DIODE 1SS400 TE61 G2070634 1- B c3
D 1040 DIODE 1SS400 TE61 G2070634 1- B c3
D 1041 DIODE DAN222 TL G2070174 1- B b2
D 1042 DIODE HVC359 TRF G2070708 1- B a2
D 1043 DIODE DAN222 TL G2070174 1- A C2
D 1044 DIODE DAN222 TL G2070174 1- A C2
D 1045 DIODE HN2D01FUTE85R G2070348 1- A C2
D 1046 DIODE HN2D01FUTE85R G2070348 1- B b2
D 1047 DIODE 1SS321 TE85R G2070076 1- A A2
D 1048 DIODE RLS135 TE-11 G2070128 1- A B1
D 1049 DIODE RB751S-40TE61 G2070850 1- B c1
D 1050 DIODE 1SS385(TE85L) G2070880 1- A A3
D 1051 DIODE 1SV307(TPH3) G2070638 1- A B2
D 1052 DIODE 1SV271 TPH3 G2070476 1- A A1
D 1053 DIODE RLS135 TE-11 G2070128 1- B c1
D 1054 DIODE 1SV307(TPH3) G2070638 1- B c1
D 1055 DIODE RB751S-40TE61 G2070850 1- B c1
D 1056 DIODE 1SV271 TPH3 G2070476 1- B c1
D 1057 DIODE 1SV271 TPH3 G2070476 1- B c1
D 1058 DIODE RLS135 TE-11 G2070128 1- B c1
D 1059 DIODE 1SV307(TPH3) G2070638 1- B c2
D 1060 DIODE 1SS400 TE61 G2070634 1- A A3

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
