Yaesu VX-7R - TECHNICAL User Manual

27
RF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
D 1061 DIODE RB751S-40TE61 G2070850 1- B d1
D 1062 DIODE 1SV271 TPH3 G2070476 1- A A1
D 1063 DIODE DAN222 TL G2070174 1- B b2
D 1064 DIODE 1SS400 TE61 G2070634 1- B a2
FB1001 CHIP COIL BLM21P300SPT L1690840 1- A C3
HS1001 HEATSINK PLATE RA0395500 1- B b1
J 1006 CONNECTOR AXK6F10335P P0091225 1- B c2
J 1007 CONNECTOR AXK6F10335P P0091225 1- B b2
J 1008 CONNECTOR IL-FPR-33S-VF-E1500 P1091138 1- A A2
L 1001 M.RFC 0.01uH ELJ-RF10NJF2 L1690831 1- A A1
L 1002 M.RFC 0.56uH LK1608 R56K-T L1690415 1- B d2
L 1003 M.RFC 0.0082uH TFL0510-8N2 L1690810 1- A A1
L 1004 M.RFC 0.01uH ELJ-RF10NJF2 L1690831 1- A A1
L 1005 M.RFC 0.033uH 2% C1608CA-33NG L1691038 1- A B1
L 1006 M.RFC 0.0068uH 5% C1608CA-6N8J L1691093 1- A B1
L 1007 M.RFC 0.01uH 2% C1608CA-10NG L1691032 1- A B1
L 1008 M.RFC 0.15uH LK1608 R15K-T L1690409 1- B c2
L 1009 M.RFC 0.056uH HK1608 56NJ-T L1690525 1- B c2
L 1010 M.RFC 0.15uH LK1608 R15K-T L1690409 1- B c2
L 1011 M.RFC 0.15uH 2% C1608CA-R15G L1691101 1- B c2
L 1012 M.RFC 0.068uH LK1608 68NM-T L1690406 1- B c2
L 1013 M.RFC 33uH LK1608 330M-T L1690690 1- B c2
L 1014 M.RFC 120uH FLC32T-121J L1690228 1- B d2
L 1015 M.RFC 27uH LK1608 270M-T L1691031 1- B d2
L 1016 M.RFC 2.2uH LK1608 2R2K-T L1690634 1- B d2
L 1017 M.RFC 33uH LK1608 330M-T L1690690 1- B d2
L 1018 M.RFC 0.0056uH TFL0510-5N6 L1690808 1- A A2
L 1019 M.RFC 0.0056uH TFL0510-5N6 L1690808 1- A A2
L 1020 M.RFC 0.01uH 2% C1608CA-10NG L1691032 1- A B2
L 1021 M.RFC 0.01uH 2% C1608CA-10NG L1691032 1- A B2
L 1022 M.RFC 0.018uH 2% C1608CA-18NG L1691035 1- A B2
L 1023 M.RFC 0.082uH 2% C1608CA-82NG L1691044 1- B b2
L 1025 M.RFC 0.082uH 2% C1608CA-82NG L1691044 1- B b2
L 1026 M.RFC 0.082uH 2% C1608CA-82NG L1691044 1- B b2
L 1027 M.RFC 0.015uH 2% C1608CA-15NG L1691034 1- B c2
L 1028 M.RFC 0.039uH 2% C1608CA-39NG L1691039 1- B b2
L 1029 M.RFC 0.1uH 2% C1608CA-R10G L1691045 1- B b2
L 1030 M.RFC 0.072uH 2% C1608CA-72NG L1691043 1- B b3
L 1031 M.RFC 0.33uH 2% C1608CA-R33G L1691106 1- B c3
L 1032 M.RFC 0.22uH 5% C1608CA-R22J L1691068 1- B c2
L 1033 M.RFC 0.22uH 5% C1608CA-R22J L1691068 1- B c3
L 1034 M.RFC 0.33uH 2% C1608CA-R33G L1691106 1- B c3
L 1035 M.RFC 0.072uH 2% C1608CA-72NG L1691043 1- B c2
L 1036 M.RFC 0.072uH 2% C1608CA-72NG L1691043 1- B c2
L 1037 M.RFC 0.01uH ELJ-RF10NJF2 L1690831 1- A B2
L 1038 M.RFC 0.01uH 2% C1608CA-10NG L1691032 1- A B2
L 1039 M.RFC 0.018uH 2% C1608CA-18NG L1691035 1- A B2
L 1040 M.RFC 0.033uH 2% C1608CA-33NG L1691038 1- A B2
L 1041 M.RFC 0.022uH TFL0510-22N L1690815 1- A C2
L 1042 M.RFC 0.022uH TFL0510-22N L1690815 1- A C2
L 1043 M.RFC 1uH LK1608 1R0K-T L1690687 1- A C2
L 1044 M.RFC 470uH FLC32T-471J L1690235 1- B a3
L 1045 M.RFC 0.027uH TFL0510-27N L1690816 1- A C2
L 1046 M.RFC 0.015uH TFL0510-15N L1690813 1- A D1
L 1047 CHIP COIL 0.047uH LQN21A47NJ04 L1690617 1- A C1
L 1048 M.RFC 0.22uH LK1608 R22K-T L1690410 1- A C1
L 1049 M.RFC 0.022uH ELJ-RE22NJF2 L1690718 USA 1- A C1
L 1049 M.RFC 0.033uH ELJ-RE33NJF2 L1690720 EXPORT 1- A C1
L 1049 M.RFC 0.022uH ELJ-RE22NJF2 L1690718 EXPORT 2- A C1
L 1049 M.RFC 0.033uH ELJ-RE33NJF2 L1690720 GERMANY 1- A C1

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
