Yaesu VX-7R - TECHNICAL User Manual

28
RF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
L 1050 M.RFC 0.1uH 2% C1608CA-R10G L1691045 1- A C1
L 1051 COIL E2 0.25-1.85-8.5T-L L0022576 1- A C1
L 1052 COIL E2 0.4-1.3-2T-L L0022580 1- A B2
L 1053 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A B1
L 1054 COIL E2 0.5-1.4-2.5T-L L0022750 1- B b1
L 1055 COIL E2 0.5-1.4-2.5T-L L0022750 1- B b1
L 1056 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- B c1
L 1057 COIL E2 0.28-1.0-11TR L0022426 1- B b1
L 1058 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- B c1
L 1059 COIL E2 0.35-1.4-3.5T-L-B L0022729 1- A A1
L 1060 COIL E2 0.35-1.4-3.5T-L-B L0022729 1- A A1
L 1061 COIL E2 0.35-1.6-4T-L L0022456 1- A A1
L 1062 COIL E2 0.35-1.6-7T-L L0022390 1- B c1
L 1063 COIL E2 0.35-1.6-7T-L L0022390 1- B c1
L 1064 COIL E2 0.35-1.6-7T-L L0022390 1- B c1
L 1065 CHIP COIL 0.22uH LQN21AR22J04 L1690600 1- B c2
L 1066 COIL E2 0.25-1.85-8.5T-L L0022576 1- B d1
L 1067 COIL E2 0.35-1.6-4T-L L0022456 1- A A1
L 1068 COIL E2 0.35-1.6-4T-L L0022456 1- A A1
L 1069 COIL E2 0.3-1.7-7T-R L0022372 1- B c1
L 1070 COIL E2 0.35-1.6-7T-L L0022390 1- B d1
L 1071 COIL E2 0.25-1.9-10.5T-L L0022749 1- B d1
L 1072 M.RFC 0.0068uH 5% C1608CA-6N8J L1691093 1- A C1
L 1073 M.RFC 0.0082uH HK1608 8N2J-T L1690515 1- A B2
L 1074 M.RFC 0.012uH TFL0510-12N L1690812 1- A B2
L 1075 M.RFC 0.012uH TFL0510-12N L1690812 1- A B2
NF1001 EMI FILTER NFM4516P13C204FT1 Q9000759 1- A C3
Q 1001 TRANSISTOR DTC144EE TL G3070075 1- A A2
Q 1002 TRANSISTOR 2SC5277-D2-TL G3352778B 1- A A2
Q 1003 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B1
Q 1004 TRANSISTOR 2SC5555ZD-TR G3355557 1- B c2
Q 1005 TRANSISTOR 2SC5555ZD-TR G3355557 1- B c2
Q 1006 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1007 TRANSISTOR 2SC5555ZD-TR G3355557 1- A B2
Q 1008 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c3
Q 1009 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B d3
Q 1010 TRANSISTOR 2SC5277-D2-TL G3352778B 1- A A2
Q 1011 TRANSISTOR 2SC5555ZD-TR G3355557 1- A C2
Q 1012 TRANSISTOR 2SC5555ZD-TR G3355557 1- B b2
Q 1013 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c3
Q 1014 TRANSISTOR 2SC5226-5-TL G3352268E 1- A C2
Q 1015 TRANSISTOR UMD6N TR G3070215 1- A C2
Q 1016 TRANSISTOR 2SC5374-TL G3353748 1- A C2
Q 1017 TRANSISTOR 2SC5374-TL G3353748 1- B b2
Q 1018 TRANSISTOR 2SC5374-TL G3353748 1- B b2
Q 1019 IC MB15A01PFV1-G-BND-EF G1092545 1- B b2
Q 1020 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B a2
Q 1021 TRANSISTOR DTA144EE TL G3070074 1- B a2
Q 1022 IC NJM12902V(TE1) G1093592 1- A D1
Q 1023 FET 2SK3475(TE12L) G3834758 1- A C1
Q 1024 TRANSISTOR 2SC5226-5-TL G3352268E 1- A C1
Q 1025 TRANSISTOR DTC143ZE TL G3070102 1- A C2
Q 1026 TRANSISTOR DTC144EE TL G3070075 1- B a1
Q 1027 FET 2SK3476(TE12L) G3834768 1- A C1
Q 1028 TRANSISTOR KRA760U-RTK G3070278 1- A C2
Q 1029 TRANSISTOR DTC144EE TL G3070075 1- A C2
Q 1030 TRANSISTOR DTC144EE TL G3070075 1- A C2
Q 1031 FET HN1J02FU(TE85L) G3070221 1- B a1
Q 1032 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A A3
Q 1033 TRANSISTOR 2SA1774 TL R G3117748R 1- A A3

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
