Yaesu VX-7R - TECHNICAL - Page 29

29
RF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
Q 1034 TRANSISTOR DTC144EE TL G3070075 1- A B2
Q 1035 TRANSISTOR DTC144EE TL G3070075 1- A A1
Q 1036 TRANSISTOR 2SA1774 TL R G3117748R 1- A A3
Q 1037 TRANSISTOR KRA760U-RTK G3070278 1- A B2
Q 1038 TRANSISTOR 2SA1774 TL R G3117748R 1- B a1
Q 1039 TRANSISTOR KRA760U-RTK G3070278 1- A B2
Q 1040 TRANSISTOR KRC654U-RTK G3070290 1- A B3
Q 1041 TRANSISTOR KRA760U-RTK G3070278 1- A B2
Q 1042 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 1043 TRANSISTOR CPH6102-TL G3070223 1- B a1
Q 1044 TRANSISTOR UMW1 TR G3070078 1- B a1
Q 1045 TRANSISTOR KRA760U-RTK G3070278 1- B a1
Q 1046 TRANSISTOR 2SA1774 TL R G3117748R 1- B a1
Q 1047 TRANSISTOR KRA755U-RTK G3070292 1- A C2
Q 1048 TRANSISTOR KRC654U-RTK G3070290 1- B a1
Q 1049 TRANSISTOR KRC654U-RTK G3070290 1- A D2
Q 1050 TRANSISTOR KRA760U-RTK G3070278 1- A C2
Q 1051 TRANSISTOR DTC144EE TL G3070075 1- A C2
Q 1052 TRANSISTOR 2SA1774 TL R G3117748R 1- A C2
Q 1053 TRANSISTOR DTC144EE TL G3070075 1- A C1
Q 1054 TRANSISTOR DTC144TE-TL G3070280 1- B a1
R 1001 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 1002 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c2
R 1003 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B c2
R 1005 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A1
R 1006 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A2
R 1007 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A2
R 1008 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A A2
R 1009 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B1
R 1010 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- A B1
R 1011 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- A B1
R 1012 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A B1
R 1013 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
R 1014 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B c2
R 1015 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B c2
R 1016 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c2
R 1017 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B c2
R 1018 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c2
R 1019 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B d2
R 1020 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d2
R 1021 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d2
R 1022 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d3
R 1023 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d2
R 1024 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d3
R 1025 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1027 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1028 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1029 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1030 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B2
R 1031 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B2
R 1032 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1033 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B2
R 1034 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B2
R 1035 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 1036 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B c2
R 1037 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B c2
R 1038 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1039 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1040 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c3
R 1042 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c3
