Yaesu VX-7R - TECHNICAL User Manual

30
RF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
R 1043 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c3
R 1044 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d3
R 1045 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d3
R 1046 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B d3
R 1049 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A A2
R 1050 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A A2
R 1051 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1052 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
R 1052 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 2- A A2
R 1053 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1054 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C2
R 1055 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A C2
R 1056 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A C2
R 1057 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A B2
R 1058 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1059 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B b2
R 1060 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B b2
R 1061 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B b3
R 1062 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1063 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B c3
R 1064 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B c3
R 1065 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c3
R 1066 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c3
R 1067 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B c3
R 1068 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c3
R 1069 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 EXPORT 1- A C2
R 1069 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 EXPORT 2- A C2
R 1069 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 USA 1- A C2
R 1069 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 GERMANY 1- A C2
R 1070 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C2
R 1071 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1072 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1073 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1074 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a2
R 1075 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1076 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1077 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B a2
R 1078 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 1079 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A C2
R 1080 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 1081 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A C2
R 1082 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 1083 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B b2
R 1084 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B b2
R 1085 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C2
R 1086 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B a3
R 1087 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
R 1088 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a2
R 1089 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- B a3
R 1090 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 GERMANY 1- B a3
R 1090 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 USA 1- B a3
R 1090 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 EXPORT 1- B a3
R 1090 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 EXPORT 2- B a3
R 1091 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b3
R 1092 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A C2
R 1093 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- A D1
R 1094 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 1095 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A D1
R 1096 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D2
R 1097 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A D1

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
