Yaesu VX-7R - TECHNICAL User Manual

31
RF Unit
R 1098 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C1
R 1099 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 1100 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A C1
R 1102 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B a3
R 1103 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 GERMANY 1- B a3
R 1103 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 USA 1- B a3
R 1103 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 EXPORT 1- B a3
R 1103 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 EXPORT 2- B a3
R 1104 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b3
R 1105 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B a1
R 1106 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B a1
R 1107 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C1
R 1108 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A C1
R 1109 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A C2
R 1110 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- A D2
R 1111 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1112 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 1113 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 1114 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 1115 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 1116 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 1118 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A B1
R 1119 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c1
R 1120 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B c1
R 1121 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B c2
R 1122 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 1123 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a1
R 1124 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B a1
R 1125 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A3
R 1126 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 1127 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A3
R 1128 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A1
R 1129 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A1
R 1130 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B c1
R 1131 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c1
R 1132 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A3
R 1133 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a1
R 1134 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B d1
R 1135 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A A1
R 1136 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
R 1137 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 1138 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a2
R 1139 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a1
R 1140 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1141 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c1
R 1142 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C1
R 1143 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 1144 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C1
R 1145 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B1
R 1146 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B c3
R 1147 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 1148 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 1149 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d2
R 1150 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C3
R 1151 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C2
TH1001 THERMISTOR ERTJ1VV473J G9090122 1- B a2
TH1002 THERMISTOR ERTJ1VV473J G9090122 1- A C1
X 1001 XTAL TSS-6 11.7MHz TSS-5032A 11.7MHZ H0103264 1- B a2
TERMINAL PLATE RA0287100 1-
INSULATOR SHEET RA0408300 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
