Yaesu VX-7R - TECHNICAL User Manual

41
AF Unit
R 2097 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C2
R 2098 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 2099 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B c2
R 2100 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c2
R 2101 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B1
R 2102 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A C2
R 2103 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- A C2
R 2104 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A C2
R 2105 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 2106 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A C2
R 2107 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A D2
R 2108 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C2
R 2109 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- A C2
R 2110 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c2
R 2111 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c2
R 2112 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B c2
R 2113 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c3
R 2114 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b2
R 2115 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B c3
R 2116 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c2
R 2117 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b3
R 2118 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b3
R 2119 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b3
R 2120 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c3
R 2121 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 2122 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B1
R 2123 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- A C2
R 2124 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- A C2
R 2125 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C2
R 2126 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 2127 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A D2
R 2128 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D2
R 2129 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D2
R 2130 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A D2
R 2131 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A D2
R 2132 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C2
R 2133 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 2134 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D3
R 2135 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B b3
R 2136 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 2137 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 2138 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 2139 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 2140 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B d2
R 2142 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2143 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B d3
R 2144 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 2145 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 2146 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D2
R 2147 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1-
S 2001 TACT SWITCH SKQTLA N5090110 1- B d3
S 2002 TACT SWITCH SKQTLA N5090110 1- B d2
S 2003 ROTARY ENCODER TP70D270E20 20F A203 Q9000789A 1- B a1
XF2001 XTAL FILTER 47.25MHz MF47R2 47.25MHZ H1102347 1- B c2
XF2002 XTAL FILTER 46.35MHz MF46R5 46.35MHZ H1102348 1- B c2
SHIELD PLATE (AF) RA0406800 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
