Yaesu VX-7R - TECHNICAL User Manual

40
AF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
R 2034 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A1
R 2035 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A A1
R 2036 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 2037 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 2038 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 2039 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 2040 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A C2
R 2043 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A D1
R 2044 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 2045 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A D1
R 2046 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 2047 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- A A1
R 2048 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 2049 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 2050 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A1
R 2051 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A A2
R 2052 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- A A1
R 2053 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 2054 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 2055 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B2
R 2056 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- A C1
R 2057 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A C1
R 2058 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 2059 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b1
R 2060 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b1
R 2061 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b1
R 2062 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b1
R 2063 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B b1
R 2064 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b2
R 2065 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A C1
R 2066 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 2067 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B b1
R 2068 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a1
R 2069 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b1
R 2070 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- B a2
R 2071 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 2072 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B a1
R 2073 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 2074 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c3
R 2075 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d3
R 2076 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C2
R 2077 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 2078 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A C2
R 2079 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a2
R 2080 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B b2
R 2081 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 2082 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B a2
R 2083 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a2
R 2084 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B b2
R 2085 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2086 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 2087 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c3
R 2088 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a2
R 2089 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c3
R 2090 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 2091 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B a2
R 2093 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c3
R 2094 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c1
R 2095 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 2096 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
