Yaesu VX-7R - TECHNICAL User Manual

39
AF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
Q 2019 TRANSISTOR 2SC5374-TL G3353748 1- A B2
Q 2020 TRANSISTOR 2SA1774 TL R G3117748R 1- A C1
Q 2021 TRANSISTOR 2SA1774 TL R G3117748R 1- A C1
Q 2022 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B b1
Q 2023 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B a2
Q 2024 TRANSISTOR 2SA1774 TL R G3117748R 1- B c3
Q 2025 TRANSISTOR 2SA1774 TL R G3117748R 1- B c3
Q 2026 TRANSISTOR 2SA1774 TL R G3117748R 1- B d3
Q 2027 TRANSISTOR DTC144EE TL G3070075 1- A C1
Q 2028 TRANSISTOR DTC144EE TL G3070075 1- B b2
Q 2029 FET 2SJ364-R(TX) G3703648R 1- A C2
Q 2030 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B a2
Q 2031 TRANSISTOR 2SC5374-TL G3353748 1- B c3
Q 2032 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B c1
Q 2033 TRANSISTOR CPH6102-TL G3070223 1- B c1
Q 2034 TRANSISTOR DTA144EE TL G3070074 1- B d1
Q 2035 TRANSISTOR DTC144EE TL G3070075 1- B d1
Q 2036 FET 2SJ364-R(TX) G3703648R 1- A C2
Q 2037 IC TA31136FN(EL) G1091605 1- B b2
Q 2038 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c2
Q 2039 TRANSISTOR DTC143ZE TL G3070102 1- B c1
Q 2040 IC TDA7233D-TR G1091112 1- A B1
Q 2041 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A C2
Q 2042 FET 2SJ364-R(TX) G3703648R 1- A D2
Q 2043 FET 2SJ364-R(TX) G3703648R 1- A C2
Q 2044 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B b3
Q 2045 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A C2
Q 2046 TRANSISTOR DTC144EE TL G3070075 1- A D2
Q 2047 FET 2SJ364-R(TX) G3703648R 1- A C2
Q 2048 IC BU4094BCFV-E2 G1093527 1- A C3
Q 2049 TRANSISTOR 2SA1774 TL R G3117748R 1- B d3
R 2002 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c2
R 2003 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c2
R 2004 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 2005 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2006 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B2
R 2007 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 2008 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B c2
R 2009 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 2010 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B2
R 2012 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B d2
R 2013 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B d2
R 2014 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A2
R 2015 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
R 2016 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A2
R 2017 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2018 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 2019 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 2021 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c2
R 2022 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B c2
R 2023 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B c2
R 2024 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d1
R 2025 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 2026 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B2
R 2028 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- A A2
R 2029 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- A A2
R 2030 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A2
R 2031 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A2
R 2032 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 2033 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B2

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
