Yaesu VX-7R - TECHNICAL User Manual

38
AF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
D 2004 DIODE DAN222 TL G2070174 1- B c1
D 2005 DIODE HVC355B(TAPE) G2070588 1- A A2
D 2006 DIODE 1SV325(TPH3) G2070848 1- A A2
D 2007 DIODE DAN222 TL G2070174 1- A D1
D 2008 DIODE DAN222 TL G2070174 1- A B2
D 2009 DIODE DAN222 TL G2070174 1- B d3
D 2010 DIODE DAN222 TL G2070174 1- B a1
D 2011 DIODE HN2D01FUTE85R G2070348 1- B c3
D 2012 DIODE MC2850-T11-1 G2070704 1- B b2
D 2013 DIODE MC2850-T11-1 G2070704 1- B b2
D 2014 DIODE RB751S-40TE61 G2070850 1- B a2
D 2015 DIODE RD6.8UMB2-T1B G2070438 1- B c1
D 2016 DIODE MC2850-T11-1 G2070704 1- B c2
D 2017 DIODE DA221 TL G2070178 1- B b3
D 2018 DIODE DA221 TL G2070178 1- B c3
FB2001 CHIP COIL BLM10A121SPT L1690843 1- A B1
FB2002 CHIP COIL BLM10A121SPT L1690843 1- A B2
FB2003 CHIP COIL BLM10A121SPT L1690843 1- A B2
FB2004 CHIP COIL BLM10A121SPT L1690843 1- A B2
FB2005 CHIP COIL BLM10A121SPT L1690843 1- A B1
FB2006 CHIP COIL BLM10A121SPT L1690843 1- A B2
J 2001 CONNECTOR IL-FHR-F40S-HF-E3000 P1091131 1- A B3
J 2002 CONNECTOR KP-269 P1091150 1- B c1
L 2001 M.RFC 0.39uH LK1608 R39K-T L1690413 1- B c2
L 2002 M.RFC 0.15uH LK1608 R15K-T L1690409 1- B c2
L 2005 M.RFC 0.47uH LK1608 R47K-T L1690414 1- A B2
L 2006 M.RFC 1uH LK1608 1R0K-T L1690687 1- A B2
L 2007 M.RFC 0.22uH LK1608 R22K-T L1690410 1- B d2
L 2008 M.RFC 0.33uH 2% C1608CA-R33G L1691106 1- B c1
L 2009 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A B2
L 2010 M.RFC 1uH LK1608 1R0K-T L1690687 1- A A2
L 2011 M.RFC 0.082uH HK1608 82NJ-T L1690527 1- A B2
L 2012 M.RFC 0.018uH 2% C1608CA-18NG L1691035 1- A A2
L 2013 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A A2
L 2014 M.RFC 0.082uH 2% C1608CA-82NG L1691044 1- A A1
L 2015 M.RFC 0.1uH LK1608 R10K-T L1690407 1- A A1
L 2016 M.RFC 0.47uH LK1608 R47K-T L1690414 1- A B1
L 2017 M.RFC 10uH 2% KQ1008TE100G L1691216 1- A C1
L 2018 M.RFC 0.33uH LK1608 R33K-T L1690412 1- B c3
L 2019 M.RFC 0.33uH LK1608 R33K-T L1690412 1- B c3
L 2020 M.RFC 0.33uH LK1608 R33K-T L1690412 1- B d2
L 2021 M.RFC 0.22uH LK1608 R22K-T L1690410 1- B d2
Q 2001 TRANSISTOR DTC144EE TL G3070075 1- B c2
Q 2002 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c2
Q 2003 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A B2
Q 2004 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- A B2
Q 2005 TRANSISTOR DTC144EE TL G3070075 1- B d3
Q 2006 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B d2
Q 2007 IC MB15A01PFV1-G-BND-EF G1092545 1- A A2
Q 2008 TRANSISTOR DTA144EE TL G3070074 1- A A2
Q 2009 TRANSISTOR 2SA1774 TL R G3117748R 1- A A1
Q 2010 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B d2
Q 2011 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- B c2
Q 2012 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A B2
Q 2013 TRANSISTOR 2SC4915-O(TE85L) G3349158O 1- A B2
Q 2014 TRANSISTOR 2SA1774 TL R G3117748R 1- A A1
Q 2015 TRANSISTOR DTC144EE TL G3070075 1- A A1
Q 2016 IC TA31136FN(EL) G1091605 1- B b1
Q 2017 TRANSISTOR 2SC5374-TL G3353748 1- A A2
Q 2018 TRANSISTOR 2SC5374-TL G3353748 1- A A1

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
