Yaesu VX-7R - TECHNICAL - Page 37

37
AF Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
C 2129 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C2
C 2130 CHIP CAP. 820pF 50V B GRM36B821K50PT K22178808 1- A C2
C 2131 CHIP TA.CAP. 4.7uF 6.3V TEMSVA20J475M-8R K78080031 1- A C2
C 2132 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D2
C 2133 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D2
C 2134 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B c2
C 2135 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- B c2
C 2136 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B c2
C 2137 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 2138 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B c2
C 2139 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b2
C 2140 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- B b2
C 2141 CHIP CAP. 0.0056uF 25V B GRM36B562K50PT K22148802 1- B b2
C 2142 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b3
C 2143 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c3
C 2144 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b3
C 2145 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b3
C 2147 CHIP TA.CAP. 1uF 25V TEMSVA1E105M-8R K78140013 1- A C1
C 2148 CHIP TA.CAP. 100uF 10V TEMSVD1A107M12R K78100031 1- A B1
C 2149 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1
C 2150 CHIP CAP. 820pF 50V B GRM36B821K50PT K22178808 1- A C2
C 2151 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C1
C 2152 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1
C 2153 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C2
C 2154 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 2156 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C2
C 2157 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A B1
C 2158 CHIP TA.CAP. 4.7uF 6.3V TMCMA0J475MTR K78080026 1- A C2
C 2159 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- A D2
C 2160 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C2
C 2161 CHIP CAP. 0.0022uF 50V B UMK105B222KW-F K22178833 1- B b3
C 2162 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A D3
C 2163 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3
C 2164 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B b3
C 2166 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b3
C 2168 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A3
C 2173 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 2174 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A3
C 2177 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2
C 2178 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- A C1
C 2179 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- A D1
C 2191 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B d2
C 2192 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2
C 2193 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1
C 2194 CHIP CAP. 56pF 50V CH UMK105CH560JW-F K22178276 1- B d2
C 2195 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B d2
C 2196 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- B d2
C 2199 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D1
C 2200 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B c1
C 2205 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C2
C 2206 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C2
C 2207 CHIP TA.CAP. 22uF 4V TESVSP0G226M-8R K78060047 1-
CD2001 CERAMIC DISC CDBM450C7 H7900930 1- B b1
CD2002 CERAMIC DISC CDBM450C7 H7900930 1- B b2
CF2001 CERAMIC FILTER SFECV10.7MS2-A-TC H3900514 1- B c2
CF2002 CERAMIC FILTER ALFYM450F=K H3900531 1- B a1
CF2003 CERAMIC FILTER ALFYM450F=K H3900531 1- B b3
D 2001 DIODE DAP222-TL G2070432 1- B c2
D 2002 DIODE 1SS400 TE61 G2070634 1- A A2
D 2003 DIODE DA221 TL G2070178 1- B c1
