AF Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR.

C 2067 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 2068 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 2069 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 2070 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A B2

C 2071 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A C1

C 2072 CHIP CAP. 330pF 50V B UMK105B331KW-F K22178823 1- A C1

C 2073 CHIP CAP. 0.0022uF 50V B GRM36B222K50PT K22178813 1- A C1

C 2074 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a1

C 2075 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 2076 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- B b1

C 2077 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B b1

C 2078 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- B b1

C 2079 CHIP CAP. 0.0056uF 25V B GRM36B562K50PT K22148802 1- B b1

C 2080 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1

C 2081 CHIP CAP. 0.0039uF 50V B UMK105B392KW-F K22178836 1- B b1

C 2082 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B b1

C 2083 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b1

C 2084 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a1

C 2085 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b1

C 2086 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D1

C 2087 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 2088 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 2089 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d3

C 2090 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A3

C 2091 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 2092 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 2094 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- A A1

C 2095 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d1

C 2096 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b2

C 2097 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b2

C 2098 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a2

C 2099 CHIP CAP. 0.0022uF 50V B UMK105B222KW-F K22178833 1- B b2

C 2100 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a2

C 2101 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b2

C 2102 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B b2

C 2103 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a2

C 2104 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B c3

C 2105 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- B c3

C 2106 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3

C 2107 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b2

C 2108 CHIP CAP. 39pF 50V CH UMK105CH390JW-F K22178272 1- B c3

C 2109 CHIP TA.CAP. 3.3uF 10V SKF-1A335M-RP K78100051 1- B c1

C 2111 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c1

C 2112 CHIP TA.CAP. 4.7uF 6.3V TEMSVA20J475M-8R K78080031 1- A C2

C 2113 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C2

C 2114 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C2

C 2115 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C2

C 2116 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b2

C 2117 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 2118 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A B2

C 2119 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 2120 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B c2

C 2121 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b2

C 2122 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B c3

C 2123 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- A C2

C 2124 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3

C 2126 CHIP TA.CAP. 220uF 10V TMCRE1A227MTR K78100064 1- A B1

C 2126 CHIP TA.CAP. 330uF 10V F931A337MNC K78100066 2- A B1

C 2127 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 2128 CHIP CAP. 0.0068uF 25V B GRM36B682J25PT K22148803 1- A C2
