Yaesu VX-7R - TECHNICAL - AF Unit Parts List

35
AF Unit
*** AF UNIT ***
PCB with Components CB1870001
Printed Circuit Board FR008210C 1-
C 2001 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- B c2
C 2002 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 2003 CHIP CAP. 0.47uF 25V B GRM40B474K25PT K22140824 1- A B2
C 2004 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- B c2
C 2005 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 2008 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B2
C 2011 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3
C 2012 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2
C 2013 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B2
C 2014 CHIP CAP. 180pF 25V CH GRM36CH181J25PT K22148201 1- A B2
C 2015 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- A B2
C 2016 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3
C 2017 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d2
C 2018 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B d2
C 2019 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2
C 2020 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A A2
C 2021 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2
C 2022 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A A2
C 2023 CHIP TA.CAP. 2.2uF 4V TESVSP0G225M-8R K78060025 1- A A2
C 2024 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- A A2
C 2026 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2
C 2027 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2
C 2029 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 2030 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B c2
C 2032 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B c2
C 2034 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d2
C 2035 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B2
C 2036 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 2037 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2
C 2038 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2
C 2039 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- A A2
C 2040 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2
C 2041 CHIP CAP. 120pF 50V CH UMK105CH121JW-F K22178284 1- A B2
C 2042 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B2
C 2043 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A A1
C 2044 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3
C 2045 CHIP CAP. 6pF 50V CH GRM36CH060B50PT K22178293 1- A A2
C 2046 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- A A2
C 2047 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A A2
C 2048 CHIP CAP. 56pF 50V CH UMK105CH560JW-F K22178276 1- A A2
C 2049 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- A A2
C 2050 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C3
C 2051 CHIP TA.CAP. 47uF 10V TEMSVC1A476M12R K78100024 1- A C3
C 2052 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B b1
C 2053 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C2
C 2054 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1
C 2055 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1
C 2056 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1
C 2058 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C2
C 2059 CHIP CAP. 9pF 50V CH GRM36CH090B50PT K22178296 1- A A2
C 2060 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A2
C 2061 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2
C 2062 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 2063 CHIP CAP. 7pF 50V CH GRM36CH070B50PT K22178294 1- A A2
C 2064 CHIP CAP. 47pF 50V CH UMK105CH470JW-F K22178274 1- A A1
C 2065 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A A1
C 2066 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A1
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
