Yaesu VX-7R - TECHNICAL User Manual

44
CNTL Unit
Side A
Parts Layout
Side B
DAN222 (N)
(D3014)
DA221 (K)
(D3015, 3016, 3017,
3018, )
HD6472237TF10
(Q3035)
NJM3403AV
(Q3018)
RH5RH651A
(Q3028)
DTA144EE (16)
(Q3008)
DTC143ZE (E23)
(Q3037)
DTC144EE (26)
(Q3007, 3011, 3013,
3014, 3015, 3019,
3036)
UMW1 (W1)
(Q3041)
2SC5374 (NA)
(Q3038)
2SC4154E (LE)
(Q3009, 3023, 3043)
2SD1801S
(Q3040)
CPH6102 (AB)
(Q3039)
DA C
1
2
3
B
4
5
6
da c
1
2
3
b
4
5
6
UMP11N (P11)
(D3028, 3029)
NJM2904V
(Q3005, 3030)
S-35L12AEFS-TB
(Q3044)
M62364FP
(Q3012)
2SJ364-R
(Q3016, 3021, 3022)
DTC124EE (25)
(Q3042)
KRX202U-RTK
(Q3029)
AT24C128N-10SI-2.7
(Q3034)
NJM12902V
(Q3006, 3010, 3020)
NJU7007F2-TE1
(Q3017)
TAR5S30
(Q3024)
NJU7231F30
(Q3025)
S-80830CNMC-B8P-T2
(Q3026, 3027)
SPMA10-1104Q7NC
(D3001, 3002)
CAUTION
Danger of explosion if battery BT3001
is in correctly replaced. Replace only
with the Same of equivalent Type.

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
