CNTL Unit
PCB with Components CB1871002 USA
PCB with Components CB1871003 VERSION A1
PCB with Components CB1871004 VERSION A2
PCB with Components CB1871005 VERSION A3
PCB with Components CB1871006 VERSION B1
PCB with Components CB1871007 VERSION B2
PCB with Components CB1871008 VERSION B3
PCB with Components CB1871009 VERSION C1
PCB with Components CB1871010 VERSION C2
PCB with Components CB1871011 VERSION C2
PCB with Components CB1871012 VERSION D1
PCB with Components CB1871013 VERSION D2
PCB with Components CB1871014 TYP:B1 GERMANY
PCB with Components CB1871015 TYP:B2 GERMANY
Printed Circuit Board FR008220C 1-
BT3001 LI-ION BATTERY MS614-FL28N Q9000783 1- B c1
C 3001 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B a5
C 3002 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B a5
C 3003 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3
C 3004 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2
C 3005 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B a5
C 3006 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B a5
C 3007 CHIP CAP. 0.0027uF 50V B UMK105B272KW-F K22178834 1- B a5
C 3008 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a5
C 3009 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- B a5
C 3011 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3
C 3012 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B a3
C 3013 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3
C 3014 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3
C 3015 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3
C 3016 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a5
C 3017 CHIP CAP. 0.015uF 50V F UMK105F153ZW-F K22179018 1- B a6
C 3018 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- B a6
C 3019 CHIP CAP. 270pF 50V B UMK105B271KW-F K22178822 1- B a6
C 3020 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a6
C 3021 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- B a6
C 3022 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B a3
C 3023 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3
C 3024 CHIP CAP. 180pF 25V CH TMK105CH181JW-F K22148244 1- B a4
C 3025 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4
C 3026 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4
C 3027 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- B a4
C 3028 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a4
C 3029 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c5
C 3030 CHIP CAP. 0.015uF 50V F UMK105F153ZW-F K22179018 1- B a6
C 3031 CHIP CAP. 270pF 50V B UMK105B271KW-F K22178822 1- B a6
C 3032 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a6
C 3033 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B b6
C 3034 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B a4
C 3035 CHIP CAP. 0.0033uF 50V B GRM36B332K50PT K22178815 1- B a4
C 3036 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a3
C 3037 CHIP CAP. 0.0022uF 50V B UMK105B222KW-F K22178833 1- B a3
C 3038 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b4
C 3039 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b4
C 3040 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b4
C 3041 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d5
C 3042 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d5
C 3043 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c5
C 3044 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B a3
C 3045 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B a3
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR.
To Next Page
