CNTL Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR.

C 3046 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B d3

C 3047 CHIP TA.CAP. 220uF 4V SK4-0G227M-RD K78060014 1- B a2

C 3048 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B d4

C 3049 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 3050 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b4

C 3051 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c4

C 3052 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c4

C 3053 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B b6

C 3054 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B b6

C 3055 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4

C 3056 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b3

C 3057 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b3

C 3060 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d4

C 3061 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c4

C 3062 AL.ELECTRO.CAP. 47uF 16V RV4-16V470MF46-RR2 K48120019 1- B a1

C 3063 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3

C 3064 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c4

C 3065 CHIP TA.CAP. 10uF 6.3V TESVSP0J106M-8R K78080055 1- B b4

C 3066 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b4

C 3067 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- B b3

C 3068 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c4

C 3069 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1

C 3070 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4

C 3080 AL.ELECTRO.CAP. 10uF 16V RV4-16V100MD46-RR2 K48120018 1- B a2

C 3081 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d4

C 3082 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c5

C 3084 CHIP TA.CAP. 33uF 10V TEMSVB21A336M-8R K78100047 1- B c3

C 3085 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B c3

C 3086 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 3087 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 3089 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d6

C 3090 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3

C 3092 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c5

C 3094 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B c2

C 3095 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B c2

C 3097 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B c2

C 3098 CHIP TA.CAP. 22uF 4V TESVSP0G226M-8R K78060047 1- B c3

C 3100 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 3101 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 3105 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2

C 3106 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B a2

C 3107 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B a2

C 3108 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- B a1

C 3109 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B b2

C 3110 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C2

C 3111 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A C2

C 3112 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B a2

C 3113 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a2

C 3114 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B b2

C 3115 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c5

C 3116 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- B c5

C 3117 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c5

C 3118 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a3

C 3119 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b2

C 3120 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b2

C 3121 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b2

C 3122 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B b2

C 3123 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c2

C 3124 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c2

C 3125 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c2

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
