Yaesu VX-7R - TECHNICAL - Page 47

47
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
C 3126 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c2
C 3127 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2
C 3129 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a4
C 3130 CHIP TA.CAP. 33uF 4V TEMSVA0G336M-8R K78060036 1- B c4
C 3131 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a3
C 3133 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c6
C 3134 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b6
C 3136 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c5
C 3137 CHIP TA.CAP. 33uF 4V TEMSVA0G336M-8R K78060036 1- B c4
C 3138 CHIP TA.CAP. 33uF 4V TEMSVA0G336M-8R K78060036 1- B d4
C 3139 CHIP TA.CAP. 22uF 4V TESVSP0G226M-8R K78060047 1- A B2
C 3140 CHIP TA.CAP. 4.7uF 6.3V TESVSP0J475M-8R K78080053 1-
C 3141 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-
C 3142 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1-
D 3001 LED SPMA10-1104Q7NC G2070878 1- A A1
D 3002 LED SPMA10-1104Q7NC G2070878 1- A D1
D 3004 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A D6
D 3005 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A C5
D 3006 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A C6
D 3007 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A B5
D 3008 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A A6
D 3009 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A A5
D 3012 DIODE UDZ TE-17 5.1B G2070448 1- B a4
D 3013 DIODE 1SS400 TE61 G2070634 1- B a3
D 3014 DIODE DAN222 TL G2070174 1- B a5
D 3015 DIODE DA221 TL G2070178 1- B a6
D 3016 DIODE DA221 TL G2070178 1- B d3
D 3017 DIODE DA221 TL G2070178 1- B c3
D 3018 DIODE DA221 TL G2070178 1- B b6
D 3019 DIODE RB521S-30 TE61 G2070642 1- B a1
D 3020 DIODE RB751S-40TE61 G2070850 1- B c4
D 3021 DIODE RB751S-40TE61 G2070850 1- B b3
D 3022 DIODE RB751S-40TE61 G2070850 1- B c1
D 3024 DIODE 1SS400 TE61 G2070634 1- B b5
D 3025 DIODE 1SS400 TE61 G2070634 1- B b5
D 3026 DIODE 1SS400 TE61 G2070634 1- B b5
D 3027 DIODE 1SS400 TE61 G2070634 1- B b5
D 3028 DIODE UMP11N TN G2070646 1- B b5
D 3029 DIODE UMP11N TN G2070646 1- B b5
D 3030 DIODE RD2.0UM-T2 G2070190 1- B b2
D 3031 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A A4
D 3032 DIODE UDZS TE-17 9.1B G2070868 1- B c3
D 3033 LED FRGB1312CE-10-TF G2070870 1- A D4
D 3034 DIODE 1SS400 TE61 G2070634 1- B c4
D 3035 DIODE RB551V-30 TE-17 G2070892 1-
DS3001 LCD MODULE LM7910FWTU Q7000426 1-
J 3001 CONNECTOR AXK6F10335P P0091225 1- B c4
J 3002 CONNECTOR IL-FHR-F30S-HF-E3000 P1091027 1- B b1
J 3003 CONNECTOR IL-FHR-F45S-HF-E3000 P1091135 1- B d2
J 3004 SHIELD FINGER 2026 3100012 S5000196 1- A B3
J 3005 SHIELD FINGER 2026 3100012 S5000196 1- A C3
L 3001 M.RFC 150uH FLC32P-T-151K L1690661 1- B b3
L 3002 M.RFC 150uH FLC32T-151J L1690229 1- B a2
MC3001 MIC. ELEMENT EM-140 M3290032 1- A D3
Q 3001 TRANSISTOR CPH6202-TL G3070265 1- A D3
Q 3002 TRANSISTOR CPH6202-TL G3070265 1- A B2
Q 3003 TRANSISTOR CPH6202-TL G3070265 1- A D3
Q 3004 TRANSISTOR CPH6202-TL G3070265 1- A C3
Q 3005 IC NJM2904V-TE1 G1091677 1- B a5
Q 3006 IC NJM12902V(TE1) G1093592 1- B a6
