Yaesu VX-7R - TECHNICAL User Manual

48
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
Q 3007 TRANSISTOR DTC144EE TL G3070075 1- B a3
Q 3008 TRANSISTOR DTA144EE TL G3070074 1- B a3
Q 3009 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B a5
Q 3010 IC NJM12902V(TE1) G1093592 1- B b6
Q 3011 TRANSISTOR DTC144EE TL G3070075 1- B a6
Q 3012 IC M62364FP 600D G1093033 1- B c6
Q 3013 TRANSISTOR DTC144EE TL G3070075 1- B a5
Q 3014 TRANSISTOR DTC144EE TL G3070075 1- B a5
Q 3015 TRANSISTOR DTC144EE TL G3070075 1- B a6
Q 3016 FET 2SJ364-R(TX) G3703648R 1- B b4
Q 3017 IC NJU7007F2-TE1 G1093617 1- B c5
Q 3018 IC NJM3403AV(TE1) G1092215 1- B a3
Q 3019 TRANSISTOR DTC144EE TL G3070075 1- B b3
Q 3020 IC NJM12902V(TE1) G1093592 1- B c6
Q 3021 FET 2SJ364-R(TX) G3703648R 1- B b3
Q 3022 FET 2SJ364-R(TX) G3703648R 1- B b3
Q 3023 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B d3
Q 3024 IC TAR5S30(TE85L) G1093570 1- B c4
Q 3025 IC NJU7231F30(TE1) G1093512 1- B c4
Q 3026 IC S-80830CNMC-B8P-T2 G1093618 1- B c4
Q 3027 IC S-80830CNMC-B8P-T2 G1093618 1- B c4
Q 3028 IC RH5RH651A-T1 G1092598 1- B b3
Q 3029 TRANSISTOR KRX202U-RTK G3070277 1- B b6
Q 3030 IC NJM2904V-TE1 G1091677 1- B b3
Q 3034 IC AT24C128N-10SI-2.7 G1093516 1- B c5
Q 3035 IC HD6472237TF10 R0663 G1093748 USA 1- B b2
Q 3036 TRANSISTOR DTC144EE TL G3070075 1- B b3
Q 3037 TRANSISTOR DTC143ZE TL G3070102 1- A C2
Q 3038 TRANSISTOR 2SC5374-TL G3353748 1- B a2
Q 3039 TRANSISTOR CPH6102-TL G3070223 1- B c5
Q 3040 TRANSISTOR 2SD1801S-TL G3418018S 1- B a3
Q 3041 TRANSISTOR UMW1 TR G3070078 1- B c5
Q 3042 TRANSISTOR DTC124EE TL G3070109 1- B b3
Q 3043 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B b5
Q 3044 IC S-35L12AEFS-TB G1093558 1- B c1
R 3001 CHIP RES. 4.7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A B2
R 3002 CHIP RES. 4.7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A C2
R 3003 CHIP RES. 47 1/4W 5% RMC1/4 470JATP J24245470 1- A D3
R 3004 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 3005 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a3
R 3006 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a3
R 3007 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A C2
R 3008 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B2
R 3009 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B2
R 3010 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B2
R 3011 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B2
R 3012 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B2
R 3013 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A B2
R 3014 CHIP RES. 47 1/4W 5% RMC1/4 470JATP J24245470 1- A D3
R 3015 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 3016 CHIP RES. 12 1/4W 5% RMC1/4 120JATP J24245120 1- A A2
R 3017 CHIP RES. 47 1/4W 5% RMC1/4 470JATP J24245470 1- A C3
R 3018 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C4
R 3019 CHIP RES. 560k 1/16W 5% RMC1/16S 564JTH J24189058 1- B a5
R 3020 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a5
R 3021 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B a5
R 3022 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B a5
R 3023 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B a5
R 3024 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- B a5
R 3025 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
