Yaesu VX-7R - TECHNICAL User Manual

49
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
R 3026 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5
R 3027 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- B a6
R 3028 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B a5
R 3029 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5
R 3030 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a5
R 3031 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B a3
R 3032 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B a3
R 3033 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a3
R 3034 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a3
R 3035 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a3
R 3036 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B a3
R 3037 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b6
R 3038 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b6
R 3039 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b6
R 3040 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b6
R 3041 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3042 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3043 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3044 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3045 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c6
R 3046 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c5
R 3047 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b6
R 3048 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b6
R 3049 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b6
R 3050 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b5
R 3051 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b5
R 3052 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b5
R 3053 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b5
R 3054 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B b5
R 3055 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b5
R 3056 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b5
R 3057 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a5
R 3058 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a6
R 3059 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a6
R 3060 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a5
R 3061 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- B a6
R 3062 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5
R 3063 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a6
R 3064 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a3
R 3065 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a3
R 3066 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a4
R 3067 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a4
R 3068 CHIP RES. 180k 1/16W 5% RMC1/16S 184JTH J24189052 1- B a4
R 3069 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B a4
R 3070 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B a4
R 3071 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B a4
R 3072 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a3
R 3073 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B a4
R 3074 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b4
R 3075 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3076 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3077 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c6
R 3079 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c6
R 3080 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c6
R 3081 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c6
R 3082 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B a3
R 3083 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B d5
R 3084 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c5
R 3085 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c6
R 3086 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B d5

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
