Yaesu VX-7R - TECHNICAL User Manual

50
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
R 3087 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b6
R 3088 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a3
R 3088 CHIP RES. 100k 1/16W 0.50% RR0510R-104-D J24189167 2- B a3
R 3089 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B c5
R 3090 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B d5
R 3091 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c5
R 3092 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B a6
R 3093 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a6
R 3094 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- B a6
R 3095 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B a4
R 3096 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a4
R 3097 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a3
R 3098 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a3
R 3099 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b4
R 3100 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b4
R 3101 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b4
R 3102 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b4
R 3103 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B a4
R 3104 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 3105 CHIP RES. 3.3M 1/16W 5% RMC1/16S 335JTH J24189324 1- B d5
R 3106 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B d5
R 3107 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5
R 3108 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a5
R 3109 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a6
R 3110 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a4
R 3111 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a3
R 3112 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 3113 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 3114 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 3115 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b3
R 3116 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b3
R 3118 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 3119 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 3120 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B c4
R 3121 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B d4
R 3122 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b6
R 3123 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B a4
R 3124 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a3
R 3125 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c4
R 3126 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c3
R 3127 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B c4
R 3128 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B c4
R 3129 CHIP RES. 2.2 1/16W 5% RMC1/16 2R2JATP J24185229 1- B b3
R 3131 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b6
R 3132 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b6
R 3133 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 3134 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B a4
R 3137 CHIP RES. 4.7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- B c3
R 3138 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b3
R 3139 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b3
R 3140 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 3141 CHIP RES. 68k 1/16W 0.50% RR0510R-683-D J24189163 1- B b2
R 3142 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A C2
R 3143 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A C2
R 3144 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B a1
R 3145 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a2
R 3146 CHIP RES. 100k 1/16W 0.50% RR0510R-104-D J24189167 1- B b2
R 3147 CHIP RES. 100k 1/16W 0.50% RR0510R-104-D J24189167 1- B b2
R 3148 CHIP RES. 100k 1/16W 0.50% RR0510R-104-D J24189167 1- B b2
R 3149 CHIP RES. 100k 1/16W 0.50% RR0510R-104-D J24189167 1- B a2

Yaesu VX-7R - TECHNICAL Specifications

General

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
