51
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
R 3150 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B c5
R 3151 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b2
R 3152 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c4
R 3153 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c4
R 3154 CHIP RES. 4.7 1/2W 5% RMC1/2 4R7JCTP J24275479 1- B a3
R 3155 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 3156 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B c5
R 3157 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 3158 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b5
R 3159 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b6
R 3160 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c1
R 3161 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c1
R 3162 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c1
R 3167 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- A B2
R 3168 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 3169 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 3170 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c4
R 3171 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B d6
R 3172 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a5
TH3001 THERMISTOR ERTJ1VV473J G9090122 1- B a2
X 3001 XTAL VT-200 32.768KHz 20PPM/6PF H0103267 1- B c1
X 3002 XTAL SX-1319 3.579545MHz 3.579545MHZ H0103229 1- B a1
MIC HOLDER RUBBER RA0405600 1-
REFLECTOR SHEET RA0399900 1-
DOUBLE FACE (LCD) RA014250A 1-
LIGHT GUIDE (LCD) RA0399100 1-
