17
Angle selection
Some DVD discs contain scenes which have been shot si-
multaneously from a number of different angles. For these
discs, the same scenes can viewed from each of the different
angles.
1 Press the ANGLE button to change the scenes from one
angle to other angle(s).
For example: 1/4, 2/4, 3/4, 4/4.
Picture Zooming
This function allows you to enlarge the picture on the TV screen
and to pan through the enlarged image.
1 Press ZOOM repeatedly to select a zoom factor as below:
ZOOM 2
ZOOM 3
ZOOM 4
ZOOM 1/2
ZOOM 1/3
ZOOM 1/4
ZOOM OFF
2 To pan though the enlarged image, press / / /
buttons to move the zoomed picture left, right, up or down.
Selecting subtilte language
This function can only be used for DVD disc recorded with
multi-subtitle language.
1 Press SUBTITLE repeatedly to select a desired language.
2 If the subtitle language is not necessary, press SUBTIT-
LE to select SUBTITLE OFF .
Notes :
In some cases, the subtitle language is not changed to
the selected one.
When a disc supporting closed caption is played, the
subtitle and the closed caption may overlap each other
on the TV screen . In this case, turn the subtitle off.
When the desired language is not selected even if the
button is pressed, the language is not available on the
disc.
When the power is turned on or the disc is replaced ,
select the subtitle language again.
Special Function

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yahoo! YDP-530 and is the answer not in the manual?

Yahoo! YDP-530 Specifications

Audio Specifications IconAudio Specifications
audio frequency response DVD20 Hz ~ 20 kHz (+/- 3.0 dB)
audio frequency response CD10 Hz ~ 20 kHz (+/- 3.0 dB)
audio signal-to-noise ratio60 dB
Video Specifications IconVideo Specifications
video signal horizontal resolution480(NTSC) / 525(PAL) lines (DVD)
video signal-to-noise ratio50 dB (DVD)
dynamic rangeDVD : 80 dB ; CD: 80 dB
Video Outputs IconVideo Outputs
CVBS video1Vp-p 75 ohms
S-Video Y1 Vp-p 75 ohms
S-Video C PAL0.3 Vp-p 75 ohms
Power IconPower
power supply120V AC 60Hz
power consumption12 W
Weight and Dimensions IconWeight and Dimensions
dimensionsW 15.4 x D 9.75 x H 2.75 inches
weight4 lbs
operation temperature32 F ~19.4 F (0°C ~ 45°C)
