Instruction #1036058B - page 3 of 10
ATTACH THE LIGHTS TO THE EXO SWINGBASE™.
3
INSTALL YOUR LICENSE PLATE.
4
EXO DOUBLEUP & EXO GEARWARRIOR
ALL OTHER APPLICATIONS
NOTE: Use the inner 2 holes unless you are using
the EXO SwingBase™ with the EXO DoubleUp™
(2-Bike Carrier) or EXO GearWarrior (Basket). If
so, use the outer 2 holes to install the EXO LitKit™.
If the EXO System is blocking
your license plate, use the license
plate mount included as part of
the EXO LitKit™. Remove your
license plate from your vehicle,
then use the 2 plastic screws
and thumbscrews to install your
license plate as shown.
ALTERNATIVE LICENSE PLATE MOUNT
Align the holes in the tubes
with the holes in the arms as
shown. Use 2 knobs to tighten
each light to the arms. Tighten
the knobs irmly to 1.5 Nm.
To Next Page
