Instruction #1036058B - page 4 of 10
INSTALL THE CLIPS.
PLUG IN THE MAIN WIRING HARNESS.
5
6
Install the 6 cable clips by
pressing them into the holes
at the locations shown.
Open the plug cover on
the EXO SwingBase™
and plug in the main
wiring harness.
