1035818C - 2/27
— LOWER SUPPORT
FRAME
UPPER
FRAME
To move the frames, pull and turn both
red triggers on the outer hubs.
LOAD ARMS
RED TRIGGER—
ROTATE THE UPPER FRAME AWAY
FROM THE LOWER FRAME.
DANGER
DO NOT INSTALL THIS
CARRIER ON A VEHICLE
LISTED AS “NO FIT”.
FITTING YOUR CAR…
Rotate the trigger
until it remains
pulled out.
FIND YOUR MEASUREMENT
IN THE FIT SHEET.
See FITTING YOUR CAR (above).
edges of the tubes.
POSITION THE FRAMES.
OR
UNLISTED VEHICLES:
POSITION THE FRAMES.
Follow these guidelines to position your frames on your car.
UPPER FRAME
upper frame until it rests on
the vehicle.
the lower frame and will
depend on vehicle shape.
LOWER FRAME
or below the numbers.
hand. If deformation occurs,
choose another location.
CAUTIONS:
that will dent under weight.
CAUTION: Some vehicles have a spoiler. If any
part of the carrier contacts the spoiler, do not
use this product.
When you see this icon, find
your vehicle at fitlookup.
yakima.com, or on the Yakima
Fit List for frame measurement,
strap positions, and critical
notes about your fit.
IF YOUR CAR IS NOT LISTED
and Canada, or see your dealer.
UNLISTED VEHICLES:
IF YOUR CAR CANNOT BE FOUND
yakima.com, or on the Yakima Fit List, or through the dealer
or Yakima) it is “unlisted”. Install the carrier as directed in
these instructions where this icon appears.
CAUTION: Although your carrier is covered by a warranty
(see final page), Yakima cannot warranty any installation
onto any vehicle that is not listed in the Yakima Fit List or
fitlookup.yakima.com.
