Yale 6116 Series User Manual

Page 2
Copyright ©2015 Yale Security Inc., an ASSA ABLOY Group Company. All rights reserved. Reproduction
in whole or in part without the express written permission of Yale Security Inc. is prohibited.
An ASSA ABLOY Group Brand.
Exit Devices
6116 Series
For technical support, contact Y ale
®
at
800.438.1951 x5033 or support@y alelocks.com
80-9460-6011-000 11/18
Table of Contents
A Verify Parts ........................................................................................................................................................................3
B 6116 Series Exit Alarm Kit - Exploded View .....................................................................................................................3
C Remove Device Assembly ................................................................................................................................................4
D Remove Existing Cover ..................................................................................................................................................... 4
E Activate & Test the New Alarm Assembly ................................................................................................................... 5 - 6
F Mounting the Switch Lever ......................................................................................................................................... 6 - 9
G Exit Bar Installation .........................................................................................................................................................10
H Testing .............................................................................................................................................................................11
I Troubleshooting ..............................................................................................................................................................11
J Maintenance ...................................................................................................................................................................11
Acronym Defi nition
PPHMS Phillips Pan Head Machine Screw
PFHUMS
Phillips Flat Head Under Cut Machine
Screw
PFHWS Phillips Flat Head Wood Screw
PPHSMS Phillips Pan Head Sheet Metal Screw
PHPNHD Phillips Pan Head Self Tapping Screw
Tools Required
Phillips
Head
Pencil
Safety Glasses
#2
Square
Socket
WARNING
This product can expose
you to lead which is
known to the state of
California to cause cancer
and birth defects or other
reproductive harm. For
more information go to
www.P65warnings.ca.gov.
08/2018

Yale 6116 Series Specifications

General

Brand	Yale
Model	6116 Series
Category	Door Opening System
Language	English
