Exit Devices
6116 Series
For technical support, contact Y ale
®
at
800.438.1951 x5033 or support@y alelocks.com
80-9460-6011-000 11/18
1. Reinstall the Device Assembly on the door (Figure 6A).
G Exit Bar Installation
Figure 6A - Device Assembly Installed on the Door
EMERGENCY
-
ALARM
WILL
S
OUND
E
XI
T
Emergency Exit
Alarm Label
Figure 6B - Adhere Emergency Exit Alarm Label
EMERGENCY EXIT - ALARM WILL SOUND
2. Adhere the Emergency Exit Alarm Label onto the fl at portion of the Touchbar (Figure 6B).
