Exit Devices
6116 Series
For technical support, contact Y ale
®
at
800.438.1951 x5033 or support@y alelocks.com
80-9460-6011-000 11/18
5. Push the Alarm Assembly until the Lockwasher prevents further advancement (Figure 5D). When the Touchbar is pressed,
the Switch Lever will move up and down enough to make contact with the Alarm Switch.
6. Reinstall all device covers and screws.
Figure 5D - Cover Skirt Assembly
LED
Touchbar
Cover Skirt Assembly
F Mounting the Switch Lever
Continued from the previous page...
Lockwasher
