F Mounting the Switch Lever
Continued from the previous page...
2. Screw the Switch Lever onto the Rear Pivot Assembly using a self tapping screw (Figure 5B),
3. Screw the Rear End Cap back into the Assembly.
Switch
Lever
#12-24 x 1/2˝
PHPNHD
Rear Pivot
Assembly
Figure 5B - Switch Lever
