Delayed Egress
7100, 7200 Series Exit Device
Installation Instructions
8094700162000 04/21
Upon depressing the pushpad for 1 second or longer, the device will sound an audible continuous tone
and allow the door to be opened within 15 (or 30) seconds. The alarm will remain as a continuous tone
until reset. Resetting of the alarm and re-arming of the device occurs automatically once the door has
been returned to the closed position for 30 seconds. The 30-second re-arming timer will re-start if the
pushpad is depressed or the door is re-opened before actual re-arming of the device occures. A DPS
(Door Position Switch) is required for the BOCA option.
NOTE: BOCA option is not suitable for installations in accordance with NFPA 101.
22 BOCA 15 Second Delay and BOCA 30 Second Delay
23 NFPA 101 Requirements: 30 Second Delay
Upon depressing the pushpad for 3 seconds or longer, the device will sound an audible continuous
tone and allow the door to be opened after 30 seconds. The alarm will remain as a continuous tone
until reset. Resetting of the alarm and re-arming of the device is accomplished by manual means only.
Note: If an external DPS is not used, Standard trim and Safe/Secure trim will allow entry without
affecting the device in an armed mode. The device will only be affected when the push pad is
depressed. Latchbolt monitor switch is a SPDT switch that monitors security of latchbolt or vertical
rods.
Latchbolt Monitor Switch
S Suffix
Latchbolt monitor switch is a SPDT switch that monitors security of latchbolt or vertical rods.
21 Additional Options Non ElectroLynx Wiring, continued
