P/N YRD216-MNL-0002 Rev G
2
What's In The Box
Loosen screw to
remove cover
Inside Lock Assembly
(Separates into 3 components)
Battery Cover
Inside Lock Mounting Plate
Installation Guide Envelope
(Includes this manual and
door checker with template)
Mounting Hardware
The mounting hardware box includes 12 components
Strike Plate
Adjustable
Deadbolt
Strike Plate
and
Deadbolt Screws
Inside Lock
Screws
Optional
Security
Strike Plate
Screws
Let's Get Started
Keypad
4 AA Batteries
Long through bolt for
1-3/4" - 2-1/4"
Door Thickness
Keys
Optional Yale
Smart Module
Optional
Fire Kit Parts
To Next Page
