P/N YRD216-MNL-0002 Rev G
4
New Door Marking Template
2
Door Checker
Check Door Measurements and
Make Adjustments If Needed
Use door checker from installation guide envelope to verify your door measurements and make any needed adjustments.
With door checker, use template from installation guide envelope to prep a new door that has not been predrilled for hardware.
Inside of Door
Installing Optional Fire Cup
O
optional
To Next Page
