Yale Assure Lock YRD216

P/N YRD216-MNL-0002 Rev G
6
4
Installing Keypad
Outside of Door
Inside of Door
Bolt must be in retracted
(unlocked) position. Note
horizontal orientation of
mechanism.
!
O
optional
