Yale Assure Lock YRD450 User Manual

Part of ASSA ABLOYP/N YRD400-KF-0022 Rev ATrusted every day
8
Template to Mark a Door for 11/2" Face Bore
FOLD OVER DOOR
EDGE
2-3/4" 70mm Backset()
For 1-3/ "4
mm(44.5)
Thick Door
CAUTION:
If printed from electronic file,
Measurea dimension
to check scale.
set print scale to 1:1.
Centerline
For 1-3/8"
35mm()
Thick Door
2-3/8" 60mm Backset()
Center
of -1/"12
( mm)38
hole through
face of door
Center
of -1/2"1
( mm)38
hole through
face of door
Center
of 1" (25mm)
hole through
edge of door
Center
of 1" (25mm)
hole through
edge of door
Door
Cut Here
