Display Switch Cluster – LCD Screen and
Warning and Indicator Lights
The LCD screen (see Figure 7) shows operator messages
for the different functions. The LCD screen can display
messages on two lines with up to 20 characters per line.
Bar graphs are also shown on the display using solid block
characters of varying heights.
The following information is displayed on the LCD screen
when the truck is running:
• Engine coolant temperature (standard)
• Fuel level, diesel and gasoline engines (standard)
The engine coolant temperature is displayed on the top line
and the fuel level is shown on the bottom line. If load
weight and travel speed options are available, press the
scroll down button to display the information for these fea-
tures. Press the scroll up button to return to the engine
coolant temperature and fuel level displays. If a fault
occurs, the fault number will be displayed on the top line.
The time of day is displayed on the right side of the top line
at all times during the selection of displayed text. "HYD
TEMP/FUNCTION REDUCED" is displayed when the
hydraulic oil temperature is higher or lower than specified
limits.
The warning lights and indicator symbols shown in Fig-
ure 7 are on all lift truck models. Depending on the equip-
ment on the lift truck, the warning and indicator lights on
the Display Switch Cluster will vary and not all the warning
and indicator lights shown in Figure 7 will illuminate. When
the warning lights and indicators are on, the operator will
see the appropriate symbol. When the warning lights and
indicators are off, the operator will see a black panel.
Unless noted in Table 3, all programmed warning and indi-
cator lights will light up for two seconds (Start Check) when
System Power is turned ON.
Model Description
27
