Legend for Figure 4
1. FLAMMABLE LP-GAS
2.
TIPOVER WARNING
3. OVERHEAD GUARD LABEL
4. WARNING, OPERATION
5. NO RIDERS
6. WARNING FOR PARKING BRAKE
7. MAST WARNING
8. NAMEPLATE
9. DRIVE TRAIN PROTECTION CAUTION
10. NO ONE ON OR UNDER FORKS
11. MAST WARNING
12. OPTIONAL FIRE SAFETY RATING
13. FAN WARNING
14. JOYSTICK LABEL
15. DIESEL FUEL LABEL (NOT SHOWN)
16. UNLEADED FUEL LABEL (NOT
SHOWN)
17. TRANSMISSION LABEL (EXAMPLE
ONLY)
18. LIFT AND TILT LABEL
19. BORON-FREE ANTIFREEZE
20. ANTIFREEZE WARNING
21. LPG TANK WARNING
22. LOCKING GAS SPRING
23. HOOD OPENING CAUTION
24. EITHER WARNING (DIESEL ONLY)
25. RADIAL TIRES AND WHEELS
(PNEUMATIC TIRES ONLY)
26. SOOT TRAP WARNING (DIESEL ONLY)
27. SPLIT WHEEL WARNING (PNEUMATIC
TIRES ONLY)
28. UL LABEL
29. STABILITY SYSTEM LABEL (ON BOTH
SIDES OF TRUCK)**
*THIS PARKING BRAKE LABEL (SEE SHEET 2) USED ON LIFT TRUCKS MANUFACTURED AFTER JANUARY, 2012.
**THIS LABEL USED ON LIFT TRUCKS MANUFACTURED AFTER JANUARY, 2012.
Display Switch Cluster
WARNING
If any of the instruments, levers, or pedals do not oper-
ate as described in the following tables, report the
problem immediately. DO NOT operate the lift truck
until the problem is corrected.
NOTE: On the lift truck models covered in this manual, the
left side (see Figure 5) of the Display Switch Cluster does
not perform any functions.
Display Switch Cluster – Right-Side Display
Inputs
The lift trucks covered in this manual can have several dif-
ferent options and configurations. Depending on the equip-
ment on the lift truck, warning and indicator lights on the
right side of the Display Switch Cluster will vary and the
truck may not contain all the warning and indicator lights
shown in Figure 6 and Table 2.
