Table 2. Display Switch Cluster – Right-Side Display Inputs (See Figure 6)
Item
No.
Item Function
1 Power ON/OFF If the lift truck is equipped with the keyless start option, lift truck system power is
turned ON by pressing
this button. To turn the lift truck system power and engine OFF,
press the Power ON/OFF button again.
If lift truck has a key switch, the Power ON/OFF symbol is replaced with the Hourmeter
symbol.
2 Engine Start
This button is used when the lift truck is equipped with the keyless start option. The
engine
is started by pressing and holding this button. Lift truck power must be turned
ON (pressing Power ON/OFF button) before starting engine.
If the lift truck contains a key switch, the Engine Start graphic is covered and the func-
tion disabled.
3 #1 Button When an operator or supervisor is in the main menu for entering and administering
passwords, this button is used to enter the number 1 for password purposes.
When an operator or supervisor is in the main menu for entering and administering
passwords, this button is used to enter the number 1 for password purposes.
4 Front Work Lights
This button controls the front work lights and the marker lights on lift trucks equipped
with this option.
Model Description
23
