Table 3. Instruments – Warning and Indicator Lights (See Figure 7) (Continued)
Item No. Item Function
12 Warning Light,
Engine
Oil
Pressure
Malfunction
Indicator
CAUTION
Stop
the engine immediately if the red light is ON while the engine is run-
ning.
The red light will illuminate when the system is not in the OFF state and the oil
pressure sensor indicates an insufficient pressure. This includes illuminating at
System Power ON until the normal operating minimum is reached. Not on at Start
Check.
When light illuminates, lift truck will enter Engine Shutdown mode, if equipped with
optional powertrain protection. See Operating Procedures section for Engine
Shutdown procedures. If truck is not equipped with optional powertrain protection
and light is illuminated when engine is running, turn engine OFF immediately and
have truck repaired by service technician.
Model Description
32
