Table 4. Operator Controls (See Figure 8) (Continued)
Item
No.
Item Function
17 Direction
Control
Switch
The Direction Control Switch for the transmission is next to the auxiliary horn but-
ton on the armrest. The Direction
Control Switch is used on lift trucks without a
Foot Directional Control pedal.
18 Auxiliary
Horn
Button
Auxiliary horn button functions when the key or keyless ignition is in the ON posi-
tion and up to 20 minutes after the key or keyless ignition is turned to the OFF
position.
Battery
Disconnect
Switch (Not
Shown
In
Figure 8)
This switch is only on units with the GS or LPS fire safety rating. The operator can
shut off all electrical
power to the lift truck by pulling up on the T-handle that is
located between the steering wheel and the parking brake.
Model Description
55
