COOLING SYSTEM
8-27
EAS27320
TROUBLESHOOTING
T
IP
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Storage box
3. Fuel tank
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, ignition and radiator fan)
Refer to “CHECKING THE FUS-
ES” on page 8-65.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-66.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-61.
Replace the main switch.
4. Check the radiator fan motor.
Refer to “CHECKING THE RADIA-
TOR FAN MOTOR” on page 8-76.
Replace the radiator fan motor.
5. Check the radiator fan motor relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-69.
Replace the radiator fan motor relay.
6. Check the coolant temperature sen-
sor.
Refer to “CHECKING THE COOL-
ANT TEMPERATURE SENSOR”
on page 8-76.
Replace the coolant temperature sensor.
7. Check the entire cooling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-25.
Properly connect or repair the cooling sys-
tem wiring.
Replace the ECU (engine control unit)
or meter assembly.
