SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
9-8
Diagnostic code: actuator operation table
Diag-
nostic
code
No.
Item Actuation Checking method
d:30 Ignition coil Actuates the ignition coil five
times at one-second inter-
vals.
Illuminates the engine trou-
ble warning light.
Check the spark five times.
• Connect an ignition
checker.
d:36 Fuel injector #1 Actuates the fuel injector #1
five times at one-second
intervals.
Illuminates the engine trou-
ble warning light.
Check the operating sound
of the fuel injector #1 five
times.
ECA59C1801
Disconnect the fuel pump
coupler.
d:37 Fuel injector #2 Actuates the fuel injector #2
five times at one-second
intervals.
Illuminates the engine trou-
ble warning light.
Check the operating sound
of the fuel injector #2 five
times.
ECA59C1801
Disconnect the fuel pump
coupler.
d:50 Fuel injection system relay Actuates the fuel injection
system relay five times at
one-second intervals.
Illuminates the engine trou-
ble warning light.
Check the operating sound
of the fuel injection system
relay five times.
d:51 Radiator fan motor relay Actuates the radiator fan
motor relay for five cycles of
five seconds. (ON 2 sec-
onds, OFF 3 seconds)
Illuminates the engine trou-
ble warning light.
Check the operating sound
of the radiator fan motor
relay five times.
d:52 Headlight relay Actuates the headlight relay
for five cycles of five seconds.
(ON 2 seconds, OFF 3 sec-
onds)
Illuminates the engine trou-
ble warning light.
Check the operating sound
of the headlight relay five
times.
d:57 Grip warmer relay Actuates the grip warmer
relay.
Illuminates the engine trou-
ble warning light.
(The light is off when the
relay is off, and the light is on
when the relay is on.)
Touch the grip warmer to
check the temperature
change.
To Next Page
