3-24
w
Be sure all people are clear of the out-
board motor when adjusting the tilt
angle, also be careful not to pinch any
body parts between the drive unit and
engine bracket.
w
Leaking fuel is a fire hazard. Disconnect
the fuel line if the engine will be tilted for
more than a few minutes. Otherwise, fuel
may leak. (If the fuel connector is provid-
ed on the motor.)
GB
EMU00289
PROCEDURE FOR TILTING UP
1) Place the gear shift lever in Neutral.
2) Remove the fuel line connection from
the motor.
3) Push the tilt lock lever to release.
4) Hold the rear of the top cowling with
one hand and fully tilt the engine up.
5) Push the tilt support knob into the
clamp bracket.
403026
EMU00299
PROCEDURE FOR TILTING DOWN
1) Slightly tilt up the engine.
2) Pull out the tilt support knob, then tilt
down the engine.
