Yamaha 2A - Adjusting Idling Speed

4-14
E
EMU01002
ADJUSTING IDLING SPEED
w
8 Do not touch or remove electrical parts
when starting or during operation.
8 Keep hands, hair and clothes away
from flywheel and other rotating parts
while engine is running.
8 2-hp model: Do not move the throttle
control lever from the start position
during warm-up. The propeller rotates
whenever the engine is running. The
boat could unexpectedly start to move
which could result in an accident.
cC
This procedure must be performed while
the outboard motor is in the water. A
flushing attachment or test tank can be
used.
A diagnostic tachometer should be used
for this procedure.
1) Start the engine and allow it to warm
up fully in Neutral until it is running
smoothly.
2-hp model: Warm the engine with
the throttle in the Start position or
less. If the outboard is mounted on a
boat, be sure the boat is tightly
moored.
2) Adjust the throttle stop-screw 1 to
set the idling speed to specification
(refer to “SPECIFICATIONS”, page 4-
1) by turning the stop-screw clock-
wise to increase the idling speed, and
turning it counterclockwise to
decrease the idling speed.
204033*
q
204035*
q
204036*
q
2
3
5
