3-31
E
EMG73210*
PROCEDURE FOR TILTING DOWN
Manual tilt model
1) Return the tilt support lever tilting up
the engine slightly.
2) Tilt down the engine.
EMG64110
PROCEDURE FOR TILTING DOWN
Power trim and tilt model
1) Push the power trim and tilt switch
“UP” until the engine is supported by
the tilt rod.
2) Release the tilt-support lever.
3) Push the power trim and tilt switch
“DN” (Down) to lower the engine to
the desired position.
EMG64011
PROCEDURE FOR TILTING DOWN
Hydro-tilt model
1) Release the tilt support lever holding
the rear of the top cowling with one
hand.
2) Tilt the engine down.
63B-9-19-3B (E) 4/18/01 11:39 AM Page 14
