A5000/A4000
22
RESULT OF THE TEST
OK :
516, 517, 518, 519: CN number
In case of OK **: the capacity (MByte) of the understanding
DRAM
In case of R/W error **: NG
NG :
In case of SWP30 access error
END OF THE TEST
After displaying the result, the test will be finihsed.
Or push the [ENC5] STOP and cancel.
07 DRIVE 1SECTOR / DMA (SCSI)
Connect the HDD to the SCSI Bus and execute by pressing the
[ENC5] MANUAL.
The SCSI ID of the drive testing on the [ENC3] can be selected. (The
default ID can be set by pressing the [ENC3] ID4.)
The data on the SCSI DRIVE may be destroyed, so execute this test
after saving the back-up data.
RESULT OF THE TEST
OK :
n : SCSI ID (0 - 7)
***
: Production Company Name
+++ : Type
### : Version
NG :
Access error
NG :
Read error
NG :
Write error
NG :
Verify error
END OF THE TEST
After displaying the result of the test, the test will be finished. Or
push on the [ENC5] STOP.
04 CPU (DRAM/EEPROM/DPRAM/FLASH)
Perform the read/write test of DRAM / EEPROM / Dual Port RAM
/ Flash ROM. Check that OK is displayed.
RESULT OF THE TEST
OK :
NG :
read error of DRAM
NG :
refresh error of DRAM
NG :
read error of EEPROM
END OF TEST
After displaying, the test will be finished.
05 WAVE RAM
Perform the read/write test of WAVE RAM (the DRAM for wave
form stuck the circuit board). Check that OK is displayed.
RESULT OF THE TEST
OK :
NG :
END OF THE TEST
After displaying the result, the test will be finished.
06 SIMM
Perform the read/write test of SWP30 register and WAVE MEMORY
(SIMM). Check that OK is displayed.
OK AUTO MANUAL
NG AUTO MANUAL
NG SCSI device bad condition
NG SCSI device read error
NG SCSI device write error
NG DATA compare error
04: CPU (DRAM/EEPROM/DPRAM/FLASH)
DESTRUCTIVE! AUTO MANUAL
04: CPU (DRAM/EEPROM/DPRAM/FLASH) OK
AUTO MANUAL
04: CPU (DRAM/EEPROM/DPRAM/FLASH) NG
DRAM Read error AUTO MANUAL
04: CPU (DRAM/EEPROM/DPRAM/FLASH) NG
Refresh error AUTO MANUAL
04: CPU (DRAM/EEPROM/DPRAM/FLASH) NG
EEPROM Read error AUTO MANUAL
05: WAVE RAM
AUTO MANUAL
06: SIMM
AUTO MANUAL
06: SIMM OK
516:
**
517:
**
518:
**
519:
**
AUTO MANUAL
06: SIMM NG
SWP access error AUTO MANUAL
07: DRIVE 1SECTOR / DMA (SCSI)
DESTRUCTIVE! ID 4 AUTO MANUAL
OK n / *** / ++++ / #####
