A5000/A4000
40
P1 P2 P3 P4 P5 P6 data data value name
size
0 [Common]
1 0 — — — — UC*8 c program name (read only)
1 1 0-31 — — — UC 0,1 controller reset for MIDI ch
A01-B16 (*5)
1 2 0-31 — — — UC 0,1 note on normal/toggle for
MIDI ch A01-B16 (*5)
1 3 — — — — UC 0,1 AD in on
1 4 — — — — UC 0-2 AD in source
1 5 — — — — SC +/-63 AD in (L) pan
1 6 — — — — UC 0-12 AD in (L) output1 (*8)
1 7 — — — — UC 0-127 AD in (L) output1 level
1 8 — — — — UC 0-12 AD in (L) output2 (*8)
1 9 — — — — UC 0-127 AD in (L) output2 level
1 10 — — — — UC 0-127 program level
1 11 — — — — UC 0-6 program LFO cycle
1 12 — — — — UC 0,1 program LFO sync
1 13 — — — — SC +/-127 program transpose
1 14 — — — — UC 25-250 program LFO tempo
1 15 — — — — UC 0-6 program LFO wave
1 16 — — — — UC 0-3 program portamento type
1 17 — — — — UC 1-127 program portamento rate
1 18 — — — — UC 1-127 program portamento time
1 19 — — — — UC 0-127 S/H speed
1 20 — — — — US 0-999 number of assigned samples
(*1) In relation to 44.1 kHz for analog in, for digital in the rates are 0:x1, 1:x1/2, 2:x1/4, 3:x1/8.
(*2) -1:off
(*3) -1:AUDITION
(*4) 128:”=Orig”
(*5) -1:”=Orig”
(*6) -2:off, -1:AUDITION, 0-15:A01-A16, 16:basic receive channel, 17-32:B01-16 (A5000 only)
(*7) -1:all
1550 US b b0:MIDI channel A01 controller reset...
b15:MIDI channel A16 controller reset
1552 US b b0:MIDI channel A01 note on normal/toggle...
b15:MIDI channel A16 note on normal/toggle
1554 SC +/-63 AD in (L) pan
1555 UC — reserved
1556 UC — reserved
1557 UC — reserved
1558 UC — reserved
1559 UC 0-127 program level
1560 SC — reserved
1561 SC — reserved
1562 SC +/-127 program transpose
1563 SC -2,-1,0-32 program LFO reset MIDI channel (*6)
1564 UC 0-3 program portamento type
1565 UC 0-127 program portamento rate
1566 UC 0-127 program portamento time
1567 UC 0-127 S/H speed
1568 UC 25-250 program LFO tempo
1569 SC -1,0-127 program LFO reset note (*7)
1570 UC*10 — reserved
-----------------------------------------------------------
1580 UC 0-1 sequence MIDI port B/A
1581 UC*15 — reserved
1596 UC 0-1 DIG&OPT output 20bit/24bit
1597 UC*2467 — reserved
Table 2 Parameter Change
data byte
Item Type Description 1st 2nd 3rd 4th
P1— P6 decimal Parameter Number —
— don’t care —
UC 1 byte (unsigned 8 bit) b7-b0 — — —
SC
1 byte (signed 8 bit,
sign,b6-b0 — — —
2’s complement)
US 2 byte (unsigned 16 bit) b15-b8 b7-b0 — —
data size
SS
2 byte (signed 16 bit,
sign,b14-b8 b7-b0 — —
2’s complement)
UL 4 byte (unsigned 32 bit) b31-b24 b23-16 b15-b8 b7-b0
SL
4 byte (signed 32 bit,
sign,b30-b24 b23-16 b15-b8 b7-b0
2’s complement)
*n n bytes of each data type —
c
All displayable ASCII
—
codes except Y
Bitmap type
value b Refer to the name column —
for bit position
—
Unused or internal use
—
only (0 not appropriate)
Parameter block
name [ ] Refer to each parameter —
block for details
2.1 Object Edit
Each data byte is divided into the upper and lower 4 bits and received/transmitted as 2 bytes
of MIDI data.
original data byte b7,b6,b5,b4,b3,b2,b1,b0
MIDI 1st byte 0,0,0,0,b7,b6,b5,b4
data 2nd byte 0,0,0,0,b3,b2,b1,b0
2.1.1 Program Parameter
1 21 0-5 0 — — UC 0,1 effect1-6 bypass (*6)
1 21 0-5 1 — — UC 0-127 effect1-6 input level (*6)
1 21 0-5 2 — — UC 0-127 effect1-6 output level (*6)
1 21 0-5 3 — — SC +/-63 effect1-6 output pan (*6)
1 21 0-5 4 — — UC 0-87 effect1-6 type (*6)
1 21 0-5 5 0-15 — SS — effect1-6parameter1-16 (*6)
1 21 0-5 6 — — UC 0-5 effect1-6 output (*6)
1 21 0-5 7 — — SC -126-0 effect1-6 width (*6)
1 22 0-3 0 — — UC 0-126 program control device 1-4
1 22 0-3 1 — — UC 0-128 progam control function 1-4
(*9)
1 22 0-3 2 — — UC 0-3 program control type 1-4
1 22 0-3 3 — — SC +/-63 program control range 1-4
1 23 — — — — UC 0-4 effect1-3 connection
1 24 — — — — UC 0-3 program LFO initial phase
1 25 — — — — UC -2,-1,0-32 program LFO reset MIDI
channel (*2)
1 26 — — — — UC -1,0-127 program LFO reset note (*3)
1 27 — — — — SC +/-63 AD in R pan
1 28 — — — — UC 0-12 AD in R output1 (*8)
1 29 — — — — UC 0-127 AD in R output1 level
1 30 — — — — UC 0-12 AD in R output2 (*8)
1 31 — — — — UC 0-127 AD in R output2 level
1 32 — — — — UC 0-4 effect4-6 connection
(A5000 only)
1 33 — — — — UC 0-6 total steps of program LFO
step wave
1 34 — — — — UC 0-3 program LFO step wave slope
1 35 0-15 — — — UC 0-127 program LFO step wave
value1-16
Easy Edit Parameters
P2 x 100 + P3 is the number of the sample (bank) assigned to the program.
P3 = 0-98 only when P2 = 9.
2 0-9 0-99 0 — — UC c assigned sample(bank) name
*16 (read only) (*10)
2 0-9 0-99 1 — — — — reserved
2 0-9 0-99 2 — — SC -1,0-32 MIDI receive channel assign
(*7)
2 0-9 0-99 3 0 — SC +/-127 level offset
2 0-9 0-99 4 0 — SC +/-127 pan offset
2 0-9 0-99 5 0 — SC +/-127 fine tune offset
2 0-9 0-99 6 0 — SC +/-127 coarse tune offset
2 0-9 0-99 7 — — UC 0-127 key limit high ( >=low)
2 0-9 0-99 8 — — UC 0-127 key limit low ( <=high)
2 0-9 0-99 9 — — UC +/-127 key range shift
2 0-9 0-99 10 — — UC 0-127 velocity limit high ( >=low)
2 0-9 0-99 11 — — UC 0-127 velocity limit low ( <=high)
2 0-9 0-99 12 — — SC -1,0,1 portamento (*4)
2 0-9 0-99 13 — — SC -1,0,1 mono mode (*1)
2 0-9 0-99 14 — — SC -1,0,1 key x-fade on (*1)
2 0-9 0-99 15 — — — — reserved
2 0-9 0-99 16 — — SC -1,0-16 alternate group number (*1)
2 0-9 0-99 17 0 — SC +/-127 AEG attack rate offset
2 0-9 0-99 18 0 — SC +/-127 AEG release rate offset
2 0-9 0-99 19 0 — SC +/-127 filter cutoff offset
2 0-9 0-99 20 0 — SC +/-31 filter Q/width offset
2 0-9 0-99 21 — — SC -1,0-12 output1 (*8)
2 0-9 0-99 22 0 — SC +/-127 output1 level offset
2 0-9 0-99 23 — — SC -1,0-12 output2 (*8)
2 0-9 0-99 24 0 — SC +/-127 output2 level offset
2 0-9 0-99 25 — — UC 0,1 MIDI control on
2 0-9 0-99 26 — — — — reserved
2 0-9 0-99 27 0 — SC +/-127 AEG decay rate offset
2 0-9 0-99 28 0 — SC +/-63 filter gain offset
2 0-9 0-99 29 0 — SC +/-127 cutoff distance offset
2 0-9 0-99 30 0 — SC +/-127 velocity x-fade low offset
2 0-9 0-99 31 0 — SC +/-127 velocity x-fade high offset
2 0-9 0-99 32 0 — SC +/-127 velocity sensitivity
2 0-9 0-99 33 — — UC — reserved
(*1) -1:”=sample”
(*2) -2:off, -1:AUDITION, 0-15:A01-16, 16:basic receive channel, 17-32:B01-16 (A5000 only)
(*3) -1:all
(*4) -1:”=sample”, 0:off, 1:”=program”
(*5) A4000, P3=0-15
(*6) A4000, P3=0-2
(*7) -1:”=sample”, 0-15:A01-A16, 16:basic receive channel, 17-32:B01-16 (A5000 only)
(*8)
value output1 output2
-1 =sample =sample
0 off off
1 stereo out assignL&R
2 effect1 assign1&2
3 effect2 assign3&4
4 effect3 assign5&6
5 assignL&R DIG&OPT
6 assign1&2 stereo out
7 assign3&4 effect1
8 assign5&6 effect2
9 DIG&OPT effect3
10 effect4 effect4
11 effect5 effect5
12 effect6 effect6
(*9)
(Easy Edit only)
(A5000 only)
(A5000 only)
(A5000 only)
